Evolving the Semiconductor Industry
We have now found a revolutionary new way of impacting multiple markets with our technology.
Everything you are doing right now involves some kind of semiconductor. Rayton is pushing the limits of cost-effective production for these materials. We plan to use our technology to create lower-cost Gallium Arsenide wafers for the semiconductor industry as a whole, which can be used in automotive, aerospace, 5G, LED, and solar applications.
The material we create serves as the foundation for all of these high-tech devices. Rayton intends to lower the cost of gallium arsenide material and then sell the wafers to the people who make these electronic devices.
Rayton has completed the Research and Development stage where we identified the implantation conditions and the recipe needed to make our wafers. We have successfully created a prototype wafer in the laboratory. We are entering the Beta Phase of operations where we plan to use the commercial-grade, high volume equipment to produce samples and are currently in pre-production. We will then begin ramping up to the production of 25 wafers per hour to enter Phase One of production.
The Problem
Silicon semi conductors simply don't cut it anymore
Silicon has played an essential role in the semiconductor industry to-date. However, we are now entering an age where certain applications require more expensive semiconductor material than silicon. In the high-frequency and high-power regimes, silicon is not suited to play a strong role.
Semiconductors such as gallium nitride, gallium arsenide, and silicon carbide (GaN, GaAs, and SiC) have better electronic properties than silicon and are currently used in the manufacturing of high-speed, high-power electronics. (1) However, the material costs for GaN, GaAs, and SiC are magnitudes higher than silicon.
The Solution
A unique process to lower the cost of this revolutionary technology
Rayton has developed a unique technology that has the potential to reduce the price point for next-generation electronics by up to 25 percent. Because of this, Rayton can play a vital role in expediting the growth of 5G infrastructure, advanced automotive electronics, cellular technology, solar cells, and more. By lowering supply costs, Rayton achieves considerable market leverage, as we seek to supply all companies fabricating electronics on these advanced materials.
*This image is an example of a wafer that Rayton would use in its manufacturing process.
The Market
The markets for products created on our wafers are diverse and increasing in demand
In the fast-growing 5G network, high-power coupled with high-frequency transistors are necessary in transmission towers and mobile handsets. GaN is particularly well suited for such applications. Further, the high-speed receivers in cellular phones will likely be built on GaAs wafers. (2)
The high-speed and high-bandwidth requirements for the 5G cellular network will require the superior properties of GaAs and GaN. These materials are also used for a wide array of cellular components. In addition, they're necessary for many other products such as proximity sensors, Wi-Fi modules, flood illuminators, and dot projectors for facial recognition (VCSEL).
The wafers used for fabrication of all these components can seamlessly be replaced by our engineered wafers without any modification of downstream equipment. Thus, Rayton’s end-product can be plugged into existing fabrication facilities, reducing material costs for those manufacturers.
There are additional high-potential growth markets that our engineered wafers will significantly impact. These include automotive, aerospace, LEDs, and solar. For instance, modern automotive technologies such as RADAR, LIDAR, 3D Imaging, blind-spot detection, and 5G-based ‘vehicle-to-x’ communication -- many of which are critical for autonomous vehicles --rely upon devices built on GaAs wafers. (4, 5, 6, 7)
What We Do
How Rayton Changes the Semiconductor Equation
Particle Accelerator Technology
We intend to use a high-current, high-voltage proton particle accelerator from Phoenix Laboratories to slice GaAs wafers, reducing waste by up to 50%. Our accelerator costs less and operates with less energy compared to competing particle accelerator methods. Because of this, our particle accelerator is capable of making up to 100 times as many wafers with the same amount of semiconductor material as our competitors use to make just one wafer. We have achieved a proof of concept wafer in the laboratory setting on non-commercial-grade equipment.
Manufacturing Efficiency
Diamond wire saws are currently the standard for cutting semiconductor materials for the electronics industry. This conventional method involves cutting the raw materials with a physical friction mechanic that wastes half the processed materials and cannot cut materials down to the two micron wafer thickness without significant yield loss or breakage.
Solar Applications
Cost-effective, highly efficient, and lightweight
Rayton intends to continue servicing the solar industry by providing a cost effective solution to high-efficient and light-weight solar cell manufacturing. The record for single junction solar cell efficiency is held by GaAs based solar cells at 28% while silicon solar cells average about 21% in production volumes. These high-efficient GaAs-based solar cells are made using Metal Organic Chemical Vapor Deposition (MOCVD) equipment. A GaAs wafer is placed in a reactive MOCVD chamber, and the solar cell is grown on top of this GaAs wafer. The initial GaAs wafer can be reused, but this step has proven to be a bottleneck in the process.
*The image above is a rendering
Rayton believes that by bringing down the cost of this initial “building block” wafer, it will reduce the cost of the entire process and unlock these types of solar cells for commercial applications. Rayton plans to sell lower cost GaAs wafers to the companies who utilize MOCVD equipment for their products. There are applications of these high-efficient and light-weight solar cells which aid the world in transforming to a fully renewable source of energy.
Where Rayton Fits In
Engineering state of the art GaAs wafers
Where does Rayton fit into the manufacturing vertical? We would buy GaAs wafers in bulk from producers like Freiberger, and Sumitomo. We would then conduct our process to lower the cost of the GaAs wafer. We would then sell our engineered GaAs wafers to the foundries like VPEC and IQE who grow devices on the wafers. They then sell these devices to the chipmakers who turn them into products used in the retail electronics we are all familiar with.
About Our Fabrication Process
First, protons are accelerated within our particle accelerator and implanted a few microns deep into a semiconductor wafer (e.g. GaAs, SiC, or GaN). Second, the implanted wafer is bonded to a less expensive, compatible carrier wafer. For example, sapphire is a good option as the carrier wafer for GaAs bonding. Third, with a thermal annealing process, a thin layer of the semiconductor material is exfoliated from its original wafer, while maintaining the bond with the carrier wafer. This process can be used to produce an engineered wafer that has a device layer of a few microns on a carrier wafer. For instance, two-micron thick layers of GaAs on sapphire can be produced. The advantage of this process is that the original wafer can be reused more than 100 times which produces over 100 engineered wafers for each source wafer.
Rayton's unique fabrication process makes use of a one-of-a-kind proton implanter jointly designed and built by Rayton and Phoenix Nuclear Labs.
*This image is a 3D-CAD rendering
The high current of this proton implanter and a unique set of magnets to shape the proton beam allows for a potential throughput that is much higher than the current industry standard and can produce an estimated $30M USD in annual revenue per production line. We believe Rayton will be well situated in the supply chain for the aforementioned high-speed, high-power electronics industry.
Specifically, we will fill the role of providing engineered substrates to epitaxy foundries and fabrication companies that will further develop the electronic components necessary for the 5G network, advanced automotive, cellular components, and other applications.
Our Roadmap
(300KeV proton implanter at Rayton's manufacturer's facility in Madison, WI)
Current Stage
Rayton plans to use this fundraising round for the advancement of our beta phase production. During this phase, Rayton will produce engineered wafers in-house to sample out to epitaxy and wafer foundries for high-speed high-power electronic components.
Once sales agreements are finalized, Rayton will then move onto single-line production. Once in revenue, Rayton will invest in more equipment to increase the throughput of the single accelerator line to reach the maximum production capability of the full-line production phase.
A breakdown of estimated costs and revenue for these three phases can be found below:
Beta Phase
The Beta phase will bring us to a full proof-of-concept where we can begin marketing our product. We need to make the final payment on the accelerator once testing is complete. This is in the amount of $954K. We have already paid about $1.4M on the accelerator. The rest of the proceeds will go towards operating the company to create samples and prepare us to raise additional capital.
The estimated timeline of our Beta Phase is 12 months beginning in Year 1. In creating our projections, we relied on assumptions that the Company will be able to make the final payment on the accelerator which is required for our product and begin using it to build sample materials. We also assume that the company will be able to create sample materials with the funds available and we estimate operating costs during this phase to be approximately $60K per month.
Phase One
We will need to buy additional semiconductor processing equipment to move into a high volume manufacturing phase which will bring us into revenue. We will need about $14M to get the company into a revenue phase that can generate approximately $9M per year or 120,000 wafers per year.
The estimated timeline of Phase 1 is 12 months beginning in Year 2. We estimate that we will be able to attain $9M in gross revenue per year provided that the company is able to attain approximately $10.12M in production equipment. We estimate that in this phase there will be $1.965M in operating expense and $2.52M in COGS. This assumes $100 per GaAs wafer with 100 uses per wafer and $20 per wafer for the handle substrates. We assume 2 shifts per day at 8 hours per shift with 300 days of operation in the year. We assume that our wholesale price per wafer would be $75.
Phase Two
We need to add on the additional semiconductor processing equipment in order to increase the throughput of the full manufacturing line. By adding this additional equipment, we can increase to the maximum throughput attainable for one accelerator of 432,000 wafers per year. This will generate an estimated $32M per year in revenue. Expenditures on the capital equipment could be reduced through the lease or purchase of used equipment.
The estimated timeline of Phase 2 is 12 months beginning in Year 3. We estimate that we will be able to attain $32M in gross revenue per year provided that the company is able to attain approximately $15.5M in additional production equipment. We estimate that in this phase there will be $5.197M in operating expense and $9.072M in COGS. This assumes $100 per GaAs wafer with 100 uses per wafer and $20 per wafer for the handle substrates. We assume 2 shifts per day at 8 hours per shift with 300 days of operation in the year. We assume that our wholesale price per wafer would be $75
The above information includes forward looking statements regarding the Company's business. Please refer to our Risk Factors in our Form C and our Forward Looking Information legend at the bottom of this Campaign Page for further details. There is no guarantee the Company will ever meet these projections and the information above includes estimates based on current data, actual results not guaranteed.
